Tubular Stranding Machine Supplier

Home › Products › Tubular Stranding Machine Supplier


Tubular Stranding Machine 01
Tubular Stranding Machine 02
Tubular Stranding Machine 03
Tubular Stranding Machine 04
  • Tubular Stranding Machine 01
  • Tubular Stranding Machine 02
  • Tubular Stranding Machine 03
  • Tubular Stranding Machine 04

Get Best Quote
Tubular Stranding Machine

Specifications

Products Stranding compact bare Aluminium and Copper wire, ACSR , Aluminium Alloy Wire and Steel Rope
Rotor Dynamically balanced and machined
Cradles Floating Type
Rotor Support Hylem under rollers
Wire guide TC bushes for wire guide
Guide Pulley Anti-Frictional guide pulleys
Bobbin Holding Shaft Type / Pintle Type
Lay Plate Special Adjustable Lay Plate Arrangement
PLC + HMI Available for easy lay and line speed setting

Features :

  • The machine is suitable for stranding 1+6 compact, bare Al/Cu wire, ACSR , Aluminum Alloy wire and Steel
  • Dynamically balanced cradles
  • Hylem rollers supported coupled steel tubes
  • Machine drive by mechanical synchronization or by individual AC motor for machine components.

Yes! I am interested

Submit Your Requirement


Product Details

Main Motor Rotor Speed Wire Dia Main Motor
KKIC / 1+6 / TSM 350 RPM 1.5-5 mm 40 HP
KKIC / 19 / TSM 250 RPM 1.5-5 mm 50 HP
