Rod Breakdown Machine Supplier


Rod Breakdown Machine
Business Type Manufacturer, Exporter, Supplier, Retailer, Wholesaler
Product Aluminium and Copper
Type Wet Type
Mechanical Elongation 8% - 46%
Click to view more

Preferred Buyer From

Location Anywhere in India

Product Details

Final Capstan Speed
800 RPM – 1400 RPM
Final Die
Rotating
Oil Storage Tank
Available
Oil Circulation System
Available
PLC + HMI
Available for easy line speed setting

Features :

  • The machine is able to draw lower sized diameter of Aluminum & Copper wire.
  • Hardened & Ground Endless Capstans.
  • Centralized Lubricating system for gears & bearings
  • Lubricant circulation system with storage
  • High performance, Hardened and ground helical gear drive
  • Heavy & robust body frame
  • Dual and multi rod model available.

Yes! I am interested


Product Details

Model Wire Dia Inlet Wire Dia Outlet Line Speed RPM of Final Capstan
KKIC/RBD-Cu/13 8.00mm 1.5 mm 22-25 M/Sec. 800-1400
KKIC/RBD-AI/13 9.50mm 1.5 mm 22-25 M/Sec. 800-1400
