Armouring Machine Manufacturer


Contact Us

Kay Kay Industrial Corporation

6-A, Industrial Estate, Sirhind Road, Patiala, Punjab - 147004, India

Mobile : +91-9417200849, +91-9888988913, +91-9376700001

Call Us : 08045135327




Features :

  • The machine is mainly used for steel round or flat AI/GI wires
  • Heavy duty fork type cage structure
  • Machine drive by mechanical synchronization or by individual AC motor drive for machine components
  • Hardened and ground gears
  • Centralized lubricating system for gears and bearings
  • Hard chrome cone with Tungsten carbide bushes
  • Heavy duty taper machined capstone with fleeting ring.

Specifications

Configuration Single Cage / Multi Cage
Type Rigid / Planetary
Fork Hexagonal fabricated robust forks
Machine Base Machined Heavy Duty
Bobbin Size 400 mm – 600 mm
Lay Plate Special Adjustable Lay Plate Arrangement
PLC + HMI Available for easy lay and line speed setting


Product Details

Model RPM of Cage Wire Dia (mm) Bobbin Size (mm)
KKIC/ARM/48B 150 1.0-5 450/500/560
KKIC/ARM/54B 130 1.0-5 450/500/560
KKIC/ARM/72B 100 1.0-5 450/500/560
KKIC/ARM/96B 80 1.0-5 450/500/560
